Ceramic Crucible Making Machine
Description:
Ceramic crucible making machine (ceramic crucible production line) is used to suppress ceramic crucible and other products. According to the need of the market and the requirements of the customers, this machine emerges as the times require. The final success of this ceramic crucible making machine is owing to the technical research by our company researchers for many years.
Due to the special shape of the crucible, suppressing difficultly becomes a major problem within the industry. The ceramic crucible production line in our company uses a unique way of demoulding which solved this problem well, improving the production efficiency greatly.
Technical Parameters of Ceramic Crucible Making Machine
Dies (sets) | 25 |
Max. Pressure (KN) | 100 |
Max. Diameter of Tablet (mm) | 28 |
Max. Depth of Fill (mm) | 30 |
Max. Thickness of Largest Tablet (mm) | 27 |
Rotational Speed of Revolving Table (r/min) | 6-20 |
Max. Capacity (pcs/h) | 15000 |
Diameter of Rotary Table | 780 |
Diameter of Middle Mould (mm) | 40 |
Diameter of Up and Low Punch Pole (mm) | 29 |
Length of the Upper Punch Pole (mm) | 175 |
Length of the Lower Punch Pole (mm) | 157 |
Dimensions (mm) | 1250×1450×1900 |
Motor(KW) | 5.5kW 4L |
Net Weight | 2000 |
